7*19 (6*19+IWS) 4mm 5mm 6mm 8mm 10mm Stainless Steel Wire Rope
Descriptions
1,Requires minimal lubrication and upkeep compared to carbon steel ropes, reducing long-term costs.
2,Widely used for sailboat rigging, mooring lines, and towing cables due to excellent corrosion resistance in saltwater environments.
3,Balanced flexibility ensures smooth winding on pulleys or drums, reducing operational friction and noise.
4,Trusted for hanging lighting, sound systems, and moving props in theaters, concerts, and event stages.
Technical Specification
| Structure | Nominal Diameter / MM | Minimum Breaking Force / KN | Reference Weight (KG/1000M) |
| AISI 304 06Cr19Ni10 | AISI 316 06Cr17Ni12Mo2 |
| 7×7(6×7+IWS)7×7(6×7+IWS) | 0.8 | 0.461 | 0.384 | 2.56 |
| 1.0 | 0.637 | 0.599 | 4.00 |
| 1.2 | 1.2 | 0.915 | 5.76 |
| 1.5 | 1.67 | 1.47 | 9.00 |
| 1.8 | 2.25 | 1.94 | 12.96 |
| 2.0 | 2.94 | 2.55 | 16.0 |
| 2.5 | 4.1 | 3.45 | 25.0 |
| 3.0 | 6.37 | 5.39 | 35.1 |
| 3.18 | 7.15 | 6.14 | 39.4 |
| 3.5 | 7.64 | 6.81 | 47.8 |
| 4.0 | 9.51 | 8.9 | 62.4 |
| 4.76 | 12.1 | 11.3 | 88.4 |
| 5.0 | 14.7 | 13.9 | 97.5 |
| 6.0 | 18.6 | 18.6 | 140 |
| 8.0 | 40.6 | 35.6 | 250 |
| 7×19(6×19+IWS)7×19(6×19+IWS) | 1.5 | 1.63 | 1.37 | 9 |
| 2.0 | 2.94 | 2.55 | 16 |
| 2.5 | 4.1 | 3.52 | 25 |
| 3.18 | 7.85 | 6.08 | 39 |
| 4.0 | 10.7 | 9.51 | 62 |
| 4.76 | 16.5 | 13.69 | 88 |
| 5.0 | 17.4 | 14.9 | 98 |
| 6.0 | 23.5 | 20.8 | 140 |
| 6.35 | 28.5 | 23.7 | 157 |
| 8.0 | 40.1 | 36.1 | 250 |
| 9.53 | 53.4 | 47.9 | 354 |
| 10 | 63 | 55 | 390 |
| 12 | 85.6 | 75 | 562 |
| 14 | 123 | 108 | 764 |
| 16 | 161 | 142 | 998 |
| 18 | 192 | 169 | 1264 |
| 20 | 237 | 209 | 1560 |
Functions and Feature
1,The steel wire rope is a helical wire bundle made of steel wires with mechanical properties and geometric dimensions that meet the requirements.
2,A steel wire rope is a rope that is twisted into strands from multiple layers of steel wire, and then a certain number of strands are twisted into a spiral with the core as the center.
3,In material handling machinery, it is used for lifting, traction, tensioning and carrying.
4,The steel wire rope has high strength, light weight, stable work, not easy to be broken suddenly, and reliable work.
Details Photos
